Part Number: 68801
Rated Line Pull: 16,500 lbs.
Motor: 12V 4.6 hp, Gen II, Series Wound
Remote Control: Remote Switch, with LED indicator 12 ft. lead
Gear Train: 3-Stage Planetary
Brake: Automatic direct drive cone
Weight: 138 lbs.
Finish: High-gloss powder coat over primer undercoating
Extreme-duty sealing helps protect the winch from the outside elements
Series-wound, high-speed motor provides fast line speed and strong pulls
Exclusive brake design provides superior control while winching
Aluminum control box cover for added protection of the electronics
Durable 3-stage planetary geartrain for smooth, reliable, operation
Remote control with 12′ (3.7m) lead and thermometric LED indicator for operator feedback
Chip-resistant powder-coated finish with primer undercoating for superior corrosion protection
90′ of 7/16″ (27m of 11mm) diameter wire rope
Backed by the WARN Limited Lifetime Warranty
The 16.5ti features the full diagnostic ability of WARN thermometric technology, plus the extreme sealing, durability, and reliability that the WARN ti-series of winches are known for. Series-wound motor combined with a 3-stage planetary geartrain delivers 16,500 lbs. of pulling power. Thermometric indicator LED provides operator feedback on motor temperature.
Service/Operating ManualsLarge-Frame Ti Winch Operators Manual
