Part Number: 27550
Rated Line Pull: 9,000 lbs single-line
Motor: Series Wound 12V 4.6 hp
Remote control: Remote Switch, 12′ Lead
Gear Train: 3-stage Planetary
Clutch (free spooling): Sliding Ring Gear
Brake: Automatic Direct Drive Cone
Weight: 85 lbs.
Finish: Argent Gray Powder Coat
Integrated control box provides excellent protection to electronics
Exclusive brake design provides superior control while winching
Durable 3-stage planetary geartrain for smooth, reliable, operation
Series-wound, high-speed motor provides fast line speed and strong pulls
Chip-resistant, powder-coated finish
Remote control with 12′ (3.7m) lead
Durable 5/16″ (8mm) diameter galvanized steel wire rope.
No-load retrieval line speed of 38′ per minute. Integrated solenoid. Runs cool with low amp draw for long winching duty cycles. Comes with 125′ of 5/16″ wire rope.
Service/Operating ManualsXD9000i Operators Manual
