Input Torque Rating: 1,250 ft-lbs

Specifications

GPI Part Number prefix: 636

Input Torque Rating: 1,250 ft-lbs/1,695 Nm

Power Rating: 595 HP/444 kW

Number of Pump Pads: 3

Weight: 242 lbs/110 kg

Features

Full fillet gearing for optimum strength

Large diameter bearings

Oil level dipstick

Options Include

Gear Ratio: 1.54 reduction to 1.54 increasing

Drive Plate Size: 8, 10, 11 1/2, and 14 or torsional coupling

Engine Adapter: SAE 5, 4, 3, 2, and 1

Clutch: SAE 3 and 2

Pump Flange Option: SAE A, B, BB, C, CC, and D

Benefits

Longer gear life

Longer bearing life

Ease of maintenance

Variety of mounting possibilities
