WARN Series 30XL-LP Hydraulic

Pulling Capacity 30,000 lbs.



Specifications

Part Numbers:

PN 80508 (Standard Drum, Air Clutch)

PN 80509 (Standard Drum, Manual Clutch)

PN 80510 (Long Drum, Air Clutch)

PN 80511 (Long Drum, Manual Clutch)



Features

14.9 cubic-inch high performance motor with 30,000 lb. capacity – great for wreckers, trailers, or severe duty applications.

Spring-applied disc brake designed to hold the full-rated load.

hardened aircraft-grade nickel chromoly two-stage planetary gear train for speed and reliability.

Standard air clutch with manual clutch option.

Available in short- and long-drum versions.

Meets SAE J706 an CE specifications.



Benefits

This winch has a 30,000lb pulling capacity and is designed for use on trailers, rollback trailers, and heavy-duty applications. LP stands for “Low Pressure” and means this winch uses a larger displacement motor to pull the full rated load at only 2320 psi. This makes the series 30XL-LP winch ideal for hydraulic systems that operate below 3000 psi.



Downloads

Sales Literature
